LED STRIP
24V COB LED Strip — 320 LEDs/m · 10W/m · 180° · Dotless · 5m Roll (Indoor) · Warm White
In Stock
Members only
Members-only pricing & ordering
Log in or sign up to see wholesale prices, specs & order.
Log in / Sign upProduct Details
Seamless dotless light — see the light, not the LEDs
Light without the dots. Unlike ordinary strips where you see each individual LED, this COB strip packs 320 densely-packed chips per meter into one continuous, seamless line of light — no spots, no dark gaps, just a smooth, elegant glow. It's the difference between seeing a row of bulbs and simply seeing light: you see the light, not the LEDs.
Because COB is encapsulated without brackets, it throws a wide 180° beam that fills the space evenly. With a premium CRI of Ra90, colours appear exactly as they should — what you see is what you get. Running on safe low-voltage 24V, the light is flicker-free, so it's comfortable and healthy for everyday living.
The strip is genuinely flexible — soft, easy to shape, and built to bend without failing, on an FPC board with 2oz double-layer electrolytic copper and double-sided film that guards against board breakage for the long haul. Cut it anywhere to get exactly the length you need, then mount it bare or inside an aluminum profile. A strong 3M adhesive backing grips harder as it warms up — just peel and stick.
Designed for indoor use, in a 5m roll, and available in warm through daylight whites plus green, red, orange, golden, and ice blue.
SPECIFICATIONS
Type: COB LED strip (dotless)
LED density: 320 chips/m
Power: 10W/m (~50W per 5m roll)
Voltage: DC 24V
Beam angle: 180° (bracket-free COB)
CRI: Ra90
Board: FPC, 2oz double-layer copper, 8mm wide
Dimensions: L5000 × W8 × H3 mm
Roll length: 5m
Backing: 3M strong adhesive
Cutting: Cut anywhere at cut points
Flicker: Flicker-free
Usage: Indoor only
Power supply: Not included
Accessories: Solder-free connectors, 90° corner joins
COLOUR OPTIONS
Warm White 3000K-3500K · Nature White 4000K-4500K · Pure White 6000K-6500K
Green · Red · Orange · Golden · Ice Blue
Features
Dotless COB light — 320 chips/m form one continuous line; see the light, not the LEDs
No spots, no dark zones — smooth, even, elegant illumination
180° wide beam — bracket-free COB encapsulation fills the space evenly
Premium CRI Ra90 — true, accurate colours; what you see is what you get
Flicker-free 24V low voltage — comfortable, healthy, and safe to use
Genuinely flexible — soft and easy to shape, bends without failing
2oz double-layer copper FPC board — double-sided film guards against board breakage
Cut anywhere — trim to exactly the length you need
Strong 3M adhesive backing — grips harder as it warms; just peel and stick
Mount bare or in profile — works equally well either way
Solder-free connectors available — including 90° corner joins for shadow-free right angles
Slim 8mm × 3mm profile — fits neatly into tight coves and channels
Perfect for: Ceiling coves & light channels · cabinets & wardrobes · display shelves · bedside & ambient lighting · interior decorative lighting (indoor use only).
How to Use
1. Prepare a 24V power supply (not included). The strip does not come with a power supply — choose an adapter or switching driver to suit your total length and installation environment (desktop adapter, slim strip driver, aluminum-case driver, cabinet sensor driver, etc.).
2. Size the supply. At 10W/m, a full 5m roll draws about 50W. Match the driver to your total wattage and add ~20% headroom (5m ≈ 50W → use a 24V 60W+ supply).
3. Cut to length. Cut at the marked cut points to get exactly the length you need.
4. Join or extend. After cutting you can solder the wires, or use solder-free connectors — including 90° corner joins for shadow-free right angles, plus connectors for extending or replacing sections. The clear hollow-design connectors don't press on the chips, so there's no dark spot at the join.
5. Peel and stick. Clean and dry the surface first, then peel the 3M backing and press the strip firmly into place — the adhesive grips harder as it warms. In dusty or rough conditions, clean the surface thoroughly and consider extra fixing. Mount bare, or fit into an aluminum profile.
6. Power on. Connect to the 24V supply, minding polarity, and switch on.
Note: this strip is for indoor use only. For long runs, feed power from both ends to keep brightness even.
